Yamato SQ510C Top-Loading Autoclave
High performance, easy operation and ergonomically designed sterilizers featuring easy top loading and handling of samples
Operation and functions
Maximum sterilizing temperature goes up to 135°C suitable for protein modification
Simply manage ordinary sterilization, sterilization of culture mediums and liquids, and melting of culture mediums
Custom programs can be saved for repeated use
Standard equipped with timer start and pre-heating features for efficient use of time and cooling fan to shorten cool down time
Mobile on wheels
Specifications
System: Automatic high-pressure steam sterilization
Operating Temp. Range: 45~135°C
Max. Working Pressure: 0.255MPa
Ambient Temperature: 5~35°C
Lid: Manual upward opening with an interlock for safety
Heater: 1000W x 2 units
Exhaust Valve: One exhaust valve and one slow release valve
Connection Ports For Optional Accessories: Total 3 ports. Female thread for sample temp. sensor (1/4" ), Female thread for chamber temp. sensor (1/4" ), Female thread pressure sensor (branching from the solenoid valve tubing)
Cooling Fan: Axial fan motor
Temp. Controller: PID control by microprocessor
Temp. Display / Setting: Digital display / digital setting by up/down keys
Timer / Timer Resolution: 0 or 1 min. to 99 hrs 59 min. / 1 minute
Operation Mode: Instrument sterilization course, liquid sterilization course, sterilization and keep warm course, melting and keep warm course, customer-programmed course
Other Features: Key locking, presetting, saving, preheating, forced cooling, sample temperature sensor (option), pattern locking, up to 20 error log saving, display of accumulated working time / present time, ON-OFF beeping setting
External Dimensions: 520 x 660 x 881 mm WxDxH
Internal Dimensions Of Chamber: 370 x D470 mm
Internal Capacity: 50L
Power Source:AC200~240V (12.5~10.5A)
Comes with our 90-day warranty.
